Unwrap a Powerful Upgrade This Christmas: Trade Up to the Acoem HiVol

09 Oct 2024

This Christmas, enhance your particle monitoring capabilities and invest in new technology at an unbeatable value!

Acoem is offering a 23% discount on the industry-leading particle monitoring system – the HiVol 3000 . Designed to deliver exceptional accuracy, reliability, and efficiency, the Acoem HiVol performs across urban air quality networks – making it the perfect gift for your business!

When you “Trade Up” to a brand new HiVol 3000 you get:

  • Top-tier performance that you can rely on
  • Unbeatable pricing for a limited time only¹

You also get Peace of Mind Guaranteed: 3-Year Return to Base Warranty²

With your Trade-up to the HiVol, enjoy a worry-free performance with our comprehensive  3-year Return to Base Warranty.  We’ve got you covered, so you can focus on what matters most to you.

Act Now:
Wherever you are in the Australasia region, contact our  nearest Acoem representative,  or email us at  email@acoem.com to know more about the special offer and secure your upgrade.

Click to unlock offer and upgrade today

The Acoem HiVol “Trade Up” promotion will run from 10 October 2024 until 16th December 2024.

Real time data insights

The HiVol 3000 is designed primarily as a particle sampler. The HiVol pump and flow controller draws a constant flow rate of ambient air through a specially prepared filter. The microprocessor based sampler features internal data logging of flow and meteorological parameters, which incorporates ambient temperature and pressure sensors. Optional attachments also allow the sampler to measure wind speed and direction which can then be used to trigger sector selectable sampling (eg fence-line monitoring).

The display on the control panel of the HiVol 3000 indicates the volumetric flow rate of air, and computes the sample volume corrected to STP conditions which means that no additional calculations are required during normal operation. This gives the HiVol 3000 an advantage over other hi-vol types that control mass flow rate.

Approvals

  • US EPA Manual Reference Method: RFPS-0706-162 approval for PM10
  • Meets Australian standard for PM10 and TSP monitoring
  • Meets RCM requirements with CE optional
  • Manufactured under ISO9001.

Specifications

  • Operation:  Microprocessor controlled (internal data logging)
  • Pump/motor:  Side channel blower driven by an induction motor (brushless)
  • Flow controller:  Variable frequency drive
  • Volumetric flow range:  Nominal 45 – 96 m3 / hr
  • Vacuum capability:  140 mBar max
  • Flow accuracy:  Better than ± 1 m3 / hr
  • Flow repeatability:  ± 1% of reading
  • Construction:  Anodized aluminum & stainless steel fasteners
  • Filter size:  250 x 200 mm rectangular element
  • Dimensions:  380mm (W) x 380mm (D) x 1200mm (H) plus inlet
  • Weight:  45 kg plus inlet weight
  • Operating voltage:  200 – 240 V + 10% 50 / 60 Hz (optional 115 V 60 Hz)
  • Power consumption:  1500 VA Max (depending on filter loading & flow rate)
  • Temp measurement range:  0 – 50 °C
  • Barometric pressure:  600 – 900 mmHg ± 4 mmHg

Know more about Acoem HiVol

The Acoem HiVol 3000 particulate sampler performs remote unattended sampling of PM2.5, PM10 or TSP across urban air quality networks.

[1] Offer applies to the HiVol unit only; Inlet sold separately.

[2] Terms & Conditions – Acoem HiVol Trade Up Promotion Offer. To apply, the Trade Up Promotion Offer must be accepted by both Acoem and the Customer before the end of the promotion period as stated above. You must be at least 18 years old to be eligible to participate. Offer may not be available in all countries. Acoem or its official representatives reserve the right to refuse or limit the incentives of any Trade Up promotion offer for any reason. Restrictions and limitations may apply/Specifications subject to change without notice.
