Acoem Air 1000

Zero air purification system

Acoem Air 1000 is a specialised plant instrument air clean up system. It is designed to remove contaminants such as SO₂, NO_x, CO, oils and particulates from plant instrument air and lower its dew point to less than –15 °C.

The resultant ‘zero air’ can then be used in a Acoem Continuous Environment Monitoring System (CEMS), or for instrument calibration. The scrubber material and filters of the air clean up system can be replaced quickly and easily by hand, without tools.

Features

Effective removal of contaminants

Chemical scrubbers are used to remove SO2, NOx, H2S and CO2 (dependent on application).

Removal option for CO

HCS 1000 heated scrubber is used to remove CO (optional).

Removal option for hydrocarbons and CO

HTO 1000HC heated scrubber is used to remove hydrocarbons and CO (optional).

Efficient multistage filtration

Deltech 810 series filter provides efficient multi-stage filtration which removes dirt, oil and water without the need for a pre-filter. Each layer removes progressively smaller particles, mist and droplets.

Quality components and inbuilt safety valve

Includes powder-coated metal panel (wall mount) with shut-off valve, Deltech mist separator, filter, coalescing regulator with gauge, safety relief valve, molecular sieve 5A scrubber, charcoal scrubber and DFU filter.

See our technology in action

Schedule a free demo to get a first-hand look at how our solutions support your business.

Schedule a free demo

Resources

8301 SERIES Zero Air Generator
Technical Specifications

Model 8301
User Manual

HTO 1000
User Manual

Applications

Discover Acoem’s case studies

Our business cases

Measuring carbon dioxide (CO2) along ocean surfaces casestudy

Monitoring for the environment & preserving history casestudy

Innovating technology for air quality monitoring

Acoem is committed to continually innovating air quality monitoring instruments and systems to meet the demands of customers around the world, including research facilities, environmental protection agencies, and industry. Our latest precision zero air generators are a cost-effective solution that allows the most up-to-date technology.
